1.4.1 TinySDK 1312B Carrier Board Hardware Feature
The TinySDK carrier board is a two-layer circuit board that demonstrates
user-friendly reference designs with all the common interfaces. Components and
interfaces (except the SD socket) are all located on one side for easy use.
LCD1 interface (on the reverse): 45Pin, 0.5mm spacing, compatible with
Mini2440/Mini6410 LCD, supports one wire precise touching
LCD2 interface (on the obverse): 40Pin, 0.5mm spacing, compatible with
Mini2440/Mini6410 LCD, supports one wire precise touching
