USB Host Pin Spec
2.3.4 Ethernet
The Mini210S integrates a RJ45 (10M/100M) Ethernet interface which uses the
DM9000 chip. Users can connect with a standard Ethernet cable to browse the internet.
2.3.5 Audio
The S5PV210 supports I2S/PCM/AC97 audio interfaces. The Mini210S uses the
I2S0 interface, and integrates a WM8960 CODEC module.
The audio output is a 3.5mm green jack. The WM8960 has a D type amplifier
therefore the Mini210S extends a Speaker socket(CON7) which can be connected to a 8
Ω 1W speaker.
The Mini210S also has a microphone input. When recording we suggest users to
move the microphone close to the audio source.
