2.3.14 IIC-EEPROM
The Mini210S has an EEPROM AT24C08 connected to CPU’s I2C0. It has 256 bytes
memory and is mainly for testing I2C bus.
Note: the S5PV210 has three I2Cs and here the Mini210 uses I2C0
2.3.15 Micro SD/TF Card
The S5PV210 has four SDIO interfaces. The SDIO0 is extended to a Micro SD/TF
socket.
2.3.16 SDIO/SD-WIFI
The S5PV210’s third SDIO is extended to CON9 which is a 2.0mm 20Pin socket. It
contains an SPI, an I2C and four GPIOs.
