ENTER THE TOSHIBA INVERTER STEPS
Press MODE until the code AUH appears
Turn ROTARY to scroll the steps
Press ROTARY to enter the value
Turn ROTARY to modify the value
Press ROTARY to enter the value
To quit: press 3 times MODE
(**) The parameters may vary depending on the software version or customisation. You
can always refer to the test inspection board supplied with the machine.
PROGRAMMING CHART OF THE TOSHIBA INVERTER
PARAMETERS
FUNCTION SET
SEt Starting SETUP region EU
CMOd RUN Command 2
FMOd Frequeancy command 3
ACC Acceleration time 1 6
dEC Deceleration time 1 1
FH Maximun frequency 100
UL Max. frequency limit 100
LL Min. frequency limit 10
uL Base frequency 1 Nom. 50
uLu Base voltage 1 230
Pt Control mode V/F 2
F400 Motor auto-tuning 2
F405 Motor Power (kw) 0,55
F415 Motor current (A) 3,1
F417 Motor speed (RPM) 1340
F701 Indication unit (A) 1
F800 Baud –Rate (38400 bps) 5
F801 Parity (1) 0
F802 Number inverter (1) 1
F829 Protocol (Modbus RTU) 1
