58
Solar Module
Ground at
Positive Pole:
Connecting
Solar Module
Strings with a
Cable Cross
Section > 16
mm²
(continued)
CAUTION! Danger of damaging the inverter by overload.
- Connect the DC+ cable to the right connection of the
inverter’s DC terminal.
- Connect the DC- cable to the left connection of the
inverter’s DC terminal.
7
3
1
6x
2
M10
3
4
DC-
8
1
DC-
AC
9
1
2
5mm
DC+
10
2
3
3
1
4
6x
M10
AC
11
1
AC
DC+
DC-
DC+
12
3
1
2
SMON
SMOFF
Tightening torque 1,2 - 1,5 Nm
Tightening torque 1,2 - 1,5 Nm
