Fronius Ignis 150 - Ignis 180 MV

Mains voltage tolerance -20% / +15%
Grid frequency 50/60 Hz
Cos phi 0.99
Max. permitted mains impedance Z
max
at PCC
1)
285 mOhm
Recommended residual current circuit breaker Type B
Welding current range (I
2
) rod electrode 10-180 A
Welding current range (I
2
) TIG 10-220 A
Welding current for MMA welding 10 min / 40 °C
(104 °F)
40 %
180 A
60 %
150 A
100 %
120 A
Welding current for TIG welding 10 min / 40°C
(104°F)
40 %
220 A
60 %
150 A
100 %
120 A
Output voltage range according to standard char-
acteristic (U
2
) rod electrode
20.4-27.2 V
Output voltage range according to standard char-
acteristic (U
2
) TIG
10.4-18.8 V
Open circuit voltage (U
0
peak) 101 V
Protection class IP 23
Type of cooling AF
Overvoltage category III
Pollution degree according to IEC60664 3
EMC emission class A
Safety symbols S, CE
Dimensions (length x width x height) 435 x 160 x 310 mm
17.1 x 6.3 x 12.2 in.
Weight 8.7 kg
19.3 lb.
Idle state power consumption
at 230 V
15 W
Welding system energy efficiency at
180 A/27.2 V
88%
1) Interface to a 230/400 V and 50 Hz public grid
Ignis 180 MV
Mains voltage (U
1
) 1 x 230 V 1 x 120 V 1 x 120 V
Max. effective primary current
(I
1eff
)
16 A 20 A 15 A
Max. primary current (I
1max
) 25 A 28 A 19 A
Max. apparent power (S
1max
) 5.75 kVA 3.48 kVA 2.28 kVA
