Fronius Primo GEN24 Series User Manual

3
Insert the DC Connector GEN24 into
the inverter and secure with the two
screws (TX20) supplied at a torque of
1.0 ‑ 1.2 Nm.
4
Manually push the DC cables through
the DC bushings.
5
Press the lock on the back of the ter-
minal and pull off the DC terminals.
6
Strip the insulation of the single con-
ductors by 18 – 20 mm.
Select the cable cross section in ac-
cordance with the instructions in Per-
missible cables for the electrical con-
nection from page 67.
157

Fronius Primo GEN24 Series Specifications

General

Type	Hybrid Inverter
THD	< 3 %
Number of MPP trackers	2
Max. efficiency	98.1 %
Protection class	IP66
DC isolation	Yes
AC Output Power	3.0 kW to 10.0 kW
Max. apparent AC power	3.0 kVA to 10.0 kVA
Max. output current (at grid voltage)	13.0 A to 43.5 A
AC nominal voltage	230 V
Number of DC connections	2
Operating Temperature Range	-25°C to +60°C
