Fronius Primo GEN24 Series User Manual

Indication of en-
ergy saving
mode
During energy saving mode:
-
Operating LED for the inverter lights up orange (see Button functions and
LED status indicator on page 35).
-
The user interface of the inverter can be reached.
-
All the available data is saved and transmitted to Solar.web.
-
The real-time data can be seen on Solar.web.
5
%
Energy-saving mode
Energy saving mode is shown on the
user interface of the inverter and in
Solar.web by an "i" beside the battery
symbol in the system overview.
25

Fronius Primo GEN24 Series Specifications

General

Type	Hybrid Inverter
THD	< 3 %
Number of MPP trackers	2
Max. efficiency	98.1 %
Protection class	IP66
DC isolation	Yes
AC Output Power	3.0 kW to 10.0 kW
Max. apparent AC power	3.0 kVA to 10.0 kVA
Max. output current (at grid voltage)	13.0 A to 43.5 A
AC nominal voltage	230 V
Number of DC connections	2
Operating Temperature Range	-25°C to +60°C
