Mount all cable and plug connections
(1-2) on the SymoFIL
Insert the Recerbo, close the inverter
and insert into the wall bracket (see
"Replacing the Display PC Board
(Recerbo)" and "Opening and Closing
Device" sections)
After switching on the inverter, carry out a
fan test via the display (see Operating Inst-
ructions)
(2)
(2)(1)
6
7

Fronius SYMO Series Specifications

General

MPPT Number	2
Frequency Range	50 / 60 Hz
Operating Temperature Range	-25°C to +60°C
Communication	WiFi, Ethernet, RS485
AC Nominal Voltage	3 x 230 V / 400 V
Output Voltage	3 x 230 V / 400 V
Warranty	5 years
