70
Press the Parameter selection button to select the welding voltage parameter
Use the adjusting dial to set the desired value for the welding voltage
The welding parameter values are shown in the digital display located above them.
All welding parameter set values that have been set using the adjusting dial or buttons on
the welding torch remain stored until the next time they are changed. This applies even if
the power source is switched off and on again in the meantime.
To display the actual welding current during welding:
- Press the Parameter selection button to select the welding current parameter
- The actual welding current is shown on the digital display during welding.
Open the gas cylinder valve
Set the shielding gas flow rate:
If there is a Feeder inching/Gas test button:
- Press the Feeder inching/Gas test button upwards
- Turn the adjusting screw on the underside of the pressure regulator until the pres-
sure gauge shows the required gas flow rate
- Press the Feeder inching/Gas test button upwards again
If there is no Feeder inching/Gas test button:
- Press the Mode button to select 4-step mode
- Set the "Ito" parameter to "Off" in the set-up menu
- Disengage the feed rollers
CAUTION!
Risk of injury and damage from electric shock and from the wire electrode emerging
at speed from the torch.
When pressing the torch trigger:
► keep the welding torch away from your face and body
► wear suitable protective goggles
► do not point the welding torch at people
► make sure that the wire electrode does not touch any conductive or earthed parts, such
as the housing, etc.
►
- press the torch trigger briefly
- turn the adjusting screw on the underside of the pressure regulator until the pres-
sure gauge shows the required shielding gas flow rate
- press the torch trigger again briefly
- engage the feed rollers
CAUTION!
Risk of injury and damage from electric shock and from the wire electrode emerging
at speed from the torch.
When pressing the torch trigger:
► keep the welding torch away from your face and body
► wear suitable protective goggles
► do not point the welding torch at people
► make sure that the wire electrode does not touch any conductive or earthed parts, such
as the housing, etc.
Press the torch trigger and start welding
