Frontier EGA/PY-3030D User Manual

Ver.1.36
2-2
Multi-Shot pyrolyzer
EGA/PY-3030D
4. Standard accessories
Quartz pyrolysis tube
2 pcs
Ultra ALLOY capillary column
5% diphenyl 95% dimethylpolysiloxane, L=30 m (i.d.=0.25mm), df=0.25 µm 1 pc
Capillary tube for evolved gas
analysis
(UADTM, deactivated tube, L=2.5 m, i.d.=0.15 mm) 1 pc
ITF needle N
2 pcs (with one ITF union)
Eco cup
Eco cup (50 µL) 20 pcs, Eco cup LF (80 µL) 20 pcs
Eco stick
Eco stick SF 10 pcs, Eco stick DF 10 pcs
Sampler
Double-Shot sampler 1 pc, Double-Shot sampler stand 1 pc, Liquid sampler 1 pc,
septum for liquid sampler 5 pcs
Graphite Vespel ferrule
3 pcs
Performance evaluation
polystyrene standard sample
Polystyrene 2.5mg film, Me-stearate 5wt% , in 2ml glass bottle.
Add 0.5ml dichloromethane, benzene or toluene to dissolve polystyrene before use.
Miscellaneous
Control software CD (Windows 10, 8.1, 8, 7, Vista, XP compatible） 1 pc, Power cable (1.5 m)
1 pc, Vinyl tube for cooling gas (1.5 m) 2 pcs, USB cable (2 m) 1 pc, Valve control cable
adapter 1 pc, Tool kit 1 set, Level vial 1 pc, Sample for performance check (polystyrene
solution containing methyl stearate, 5 µg/µL) 1 pc (0.5 ml), Eco pickup F 5 pcs, Eco stand AL
5 pcs, Operation manual (pdf)
5. Miscellaneous
Power
AC100/120V (50/60 Hz) 400W (MAX) or AC200/240V (50/60 Hz) 400W (MAX)
Dimension
Pyrolyzer unit
Temperature controller
76(W) x 143(D) x 150(H) mm/1.6kg (less cables, excluding protuberances)
120(W) x 310(D) x 310(H) mm/5.4kg or 120(W) x 310(D) x 310(H) mm/ 7.6kg
Recommended GC and GC/MS
Agilent: Agilent 7890 GC, Agilent 5975 GC/MS
Jeol: JMS-Q1000GC Mk II
Perkin Elmer: Clarus GC, GC/MS
Shimadzu: GCMS-QP2010, GC-2010
Thermo Fisher: Trace GC, Trace ISQ
SCION / Bruker: SCION GC
Others: Contact us for details
6. Options
Peripheral device
 AS-1020E: Auto sampler for Multi-Shot pyrolyzer (automated analysis of max 48 samples)
 CGS-1050Ex: Carrier gas selector (switches between air and He, use with SS-1010E
recommended)
 MJT-1035E: MicroJet Cryo-Trap (completely traps compounds of C
4
or greater by cooling
the head of a column with liquid nitrogen jet in GC oven)
 PY-1110E: F-Search system (evolved gases from polymer / pyrogram-MS library, additive
library, pyrolyzates library)
 PY1-1050: On-line micro reaction sampler (introduces compounds generated at high
temperatures/pressures into separation column)
 PY1-1060: Micro thermal desorption sampler (allows for the thermal desorption analysis of
volatile gases)
 SS-1010E: Selective Sampler (selectively introduces any temperature zone on EGA
thermogram into a separation column with the use of gas pressure difference)
 UV-1047Xe: Micro UV irradiator (comes with 1 pc of On-line micro UV sampler)
 PY-7105E: Thermometer (used to measure the Multi-Shot pyrolyzer furnace temperature)
Consumables
 Vent-free GC/MS adapter
 PY-K303D: Consumables set (estimated annual use for Multi-Shot pyrolyzer)
 PY-K313D:Consumables set (estimated annual use for Multi-Shot pyrolyzer with
AS-1020E)
 Ultra ALLOY Metal capillary columns (id=0.25, 0.53 mm, L=5~60 m, variety of chemically
bonded stationary liquid phases)
