3-10
Ver.1.36
3.10 FRONT, REAR, SIDES, AND TOP VIEWS
3.10.1 Pyrolyzer
Views from different angles of the pyrolyzer are shown in Fig 3.8.
Fig. 3.8 Views from different angles of pyrolyzer
ITF cover
ITF needle
ITF union N
Cooling fan
Carrier gas tube
Cooling gas Inlet port
Cable connectors
Exhaust of cooling gas
Liquid Sampler
Sampler base
Sampler base fixing
screws
O-ring P-6W
O-ring P-12
Side view
Rear view
Front view
Furnace purge gas tube
