CHAPTER 3 INSTALLATION
In this chapter, the overview of the installation process is described. For detailed installation
instructions, consult the installation manual that comes with the installation kit for your GC model.
3.1 PREPARING INSTALLATION
3.1.1 Before installation
Ensure that you have the following items before installing the pyrolyzer. These are not included in the
package.
For your specific GC model
Not included in this package
(purchased separately)
AC100/120V or AC200/240V,
400W (MAX)
Plug with a ground pin
Supplied power cable is 2 m long.
OS: Windows 10, 8.1, 8, 7, Vista,
XP
One USB port
CD ROM drive
PC that controls GC or GC/MS can be
shared. Supplied USB cable is 2 m long.
Compressed air or nitrogen gas
Pressure: 500~800 kPa
Consumption: about 7L/min
(at 600 kPa)
1/8 in female Swagelok outlet must be
accessible within 1.5 m from the
temperature controller. Alternatively, 1/8
in or 3 mm pipe can be used for
connection with supplied nylon tube
having flow restrictor.
Vent-free GC/MS adapter
2)
Part No. : MS402180
MS402190
MS402195
(Depends on GC/MS model)
*Optional
Permits switching of separation columns
while maintaining vacuum of MS.
Space for temperature controller
Width: 20 cm
Depth: 35 cm or more
The length of cable connecting the
pyrolyzer to temperature controller is 2 m.
1) Air used for FID can be branched and used; however, high sensitivity FID work may be affected by this gas
sharing.
2) The use of this adapter greatly saves time when switching columns and or an EGA tube and is a must-have
item for productive analytical work.
1. For your safety, wear protective goggles to protect your eyes
during operation.
2. Before installation to your GC, TURN OFF the injection port
temperature and wait until it drops below 100°C, or you are running
at the risk of burns.
3. While installing the pyrolyzer to your GC. Be sure to TURN OFF
the power of the temperature controller. If the pyrolyzer is
powered, it quickly becomes very hot.
