Frontier EGA/PY-3030D - 4.3 SET-UP ANALYTICAL MODES AND OPERATION

4-7
Ver.1.36
4.3 SET-UP ANALYTICAL MODES AND OPERATION
Four analytical modes: Single-Shot Analysis, Double-Shot Analysis, Direct EGA Analysis, Heart-Cut
EGA Analysis are available.
4.3.1 Set-up for Single-Shot Analysis and operation procedure
From the menu bar, select “Tool” – “Analytical Modes” – “Single-Shot Analysis”, or click on the
“Single-Shot Analysis” icon (A) on the toolbar. The set-up screen shown in Fig. 4.7 will be displayed.
Fig. 4.7 Set-up screen for Single-Shot Analysis
B.
C. Pyrolysis temperature
(40 – 1050°C)
A.
D. Hold time at pyrolysis temperature
E.
