TRANSPORTING
24
TRANSPORT LOCK OPTIONS
Depending on your rake’s configuration, the length of the transport lock will vary.
Lock has a series of holes in both outside and inside sections; center pin (A) holds sections in place at desired
width.
12 tine wheels, no center kicker option: 37-7/8" (96 cm) 12 tine wheels, center kicker option: 47-7/8" (122 cm)
14 tine wheel option, no center kicker: 45-5/8" (116 cm) 14 tine wheel option, center kicker option: 45-5/8" (116 cm)
A
