Frontier WR2214 - Page 81

DRAWBAR
KEY PART NO. PART NAME QTY SERIAL NO.
W
R
2
2
1
2
W
R
2
2
1
4
REMARKS
1 5TNP50FV154 REAR DRAWBAR DM 01 …...….. - XFWR22X001074 X X
5TNP50FV167 REAR DRAWBAR DM th6 01 XFWR22X001075 - up X X
2 5TNP50FV170 SLIDING DRAWBAR DM 01 X X
3 5TNP50FV171 FRONT DRAWBAR DM 01 X X
4 5TNP70AV123 PLATE 530x180x15 12 HOLES D.15 01 …...….. - XFWR22X001074 X X
5TNP50ZV398 REINFORCED REAR CONNECT. PLATE 01 XFWR22X001075 - up X X
5 5TNV10AZ137 SCREW TE 14x170 UNI5737 ZINCED 12 X X
6 TNV20CZ004 NUT METABLOCK M14 DIN 980 ZINCED 20 X X
7 5TNV10AZ132 SCREW TE M14x 40 10.9 UNI5737 08 X X
8 TNV40CZ008 SPLIT PIN R d=4 ZINCED 06 X X
9 5TNV85A0007 NYLON 70x50x10 WITH HOLES 04 …...….. - XFWR22X001074 X X (USE WITH 5TNP50FV154)
5TNV85A0023 NYLON 70x50x8.5 WITH HOLES 04 XFWR22X001075 - up X X (USE WITH 5TNP50FV167)
10 5TNV10BZ009 SCREW T.C.B. M8x20 DIN7984 gr 08 …...….. - XFWR22X001074 X X (USE WITH 5TNP50FV154)
5TNV10BZ118 SCREW M8x16 10.9 ZINC 08 XFWR22X001075 - up X X (USE WITH 5TNP50FV167)
11 5TNV85A0009 NYLON 119x55x10 02 X X
12 5TNV85A0008 NYLON 99x55x10 02 X X
13 5TNP70CZ122 ANGLE PLATE 04 X X
14 TNV30AZ001 WASHER M6 UNI 6592 ZINCED 08 X X
15 5TNV10AZ001 SCREW TE M6x12 UNI 5739 08 X X
16 TNC70BZ072 PIN FOR STAND DRAWBAR D.12 ZINCED 01 X X
17 TNV40CZ006 SPLIT PIN R D=2.5 ZINCED 01 X X
18 5TNC70BZ094 PIN 02 X X
19 5TNP50HZ019 BRACKET ADJUSTMENT TRACTOR 01 X X
20 TNP50ZV007 STAND COMPLETE FOR DRAWBAR 01 X X
21 5TNP50MZ004 BLADE FOR BRACKET ZINCED T/V 01 X X
22 5TNP50HV061 ATTACHMENT FOR TRANSPORT BAR 01 X X
23 TNV20CZ005 NUT METABLOCK M16 DIN 980 ZINCED 04 X X
24 5TNC30AZ041 VERROU M16 MALE 04 X X
25 TNV20CZ003 NUT METABLOCK M12 DIN 980 ZINCED 02 X X
26 5TNP50UV025 TRANSPORT BAR 02 X X
27 5TNC45CZ005 LOCK PIN WITH CHAIN ZINCED 04 X X
28 5TNV10AZ111 SCREW TE M14x50 UNI 5737 ZINCED 04 X X
29 5TNP50HV062 FRAME ATTACHMENT FOR TRANSPORT BAR 02 X X
30 TNV10AZ046 HEX.CAP SCREW TE M12x140 UNI 5737 02 X X
31 TNV85C0001 CAP D=14 02 X X
32 TNC45BZ001 SAFETY CHAIN 01 X X
80
