Signal selection block “Input1 X terminal (0 - 15)” items (Only Real-time trace / Historical trace)
No Item
0 0:Multistep speed selection[SS1]
1 1:Multistep speed selection[SS2]
2 2:Multistep speed selection[SS4]
3 3:Multistep speed selection[SS8]
4 4:ASR and ACC/DEC time[RT1]
5 5:ASR and ACC/DEC time[RT2]
6 6:3-wire operation stop command[HLD]
7 7:Coast-to-stop command[BX]
8 8:Alarm reset[RST]
9 9:Trip command(External fault)[THR]
10 10:Jogging operation[JOG]
11 11:Speed setting 2/1[N2/N1]
12 12:Motor M2 selection[M-CH2]
13 13:Motor M3 selection[M-CH3]
14 14:DC brake command[DCBRK]
15 15:ACC/DEC cleared to zero[CLR]
Signal sel
ection block “Input2 X terminal (16 - 31)” items (Only Real-time trace / Historical trace)
No Item
0 16:UP/DOWN creep speed[CRP-N2/N1]
1 17:UP/DOWN UP command[UP]
2 18:UP/DOWN DOWN command[DOWN]
3 19:Write enable for KEYPAD[WE-KP]
4 20:PID control cancel[KP/PID]
5 21:Inverse mode changeover[IVS]
6 22:Interlock signal 52-2[IL]
7 23:Write enable for link[WE-LK]
8 24:Operation selection through link[LE]
9 25:Universal DI[U-DI]
10 26:Pick up start mode[STM]
11 27:Synchronization command[SYC]
12 28:Zero speed locking command[LOCK]
13 29:Pre-excitation command[EXITE]
14 30:Speed ref. limiter cancel[N-LIM]
15 31:H41(Torque cmd.)cancel[H41-CCL]
Signal selection block “Input3 X terminal (32 - 47)” items (Only Real-time trace / Historical trace)
No Item
0 32:H42(Torque current cmd)cancel[H42-CCL]
1 33:H43(Flux cmd.)cancel[H43-CCL]
2 34:F40(Torque limiter cmd.)cancel[F40-CCL]
3 35:Torque limiter 2/1[TL2/TL1]
4 36:Bypass from ramp func. generator[BPS]
5 37:Torque bias reference 1[TB1]
6 38:Torque bias reference 2[TB2]
7 39:DROOP selection[DROOP]
8 40:Ai1 zero hold command[ZH-Ai1]
9 41:Ai2 zero hold command[ZH-Ai2]
10 42:Ai3 zero hold command[ZH-Ai3]
11 43:Ai4 zero hold command[ZH-Ai4]
12 44:Ai1 polarity change[REV-Ai1]
13 45:Ai2 polarity change[REV-Ai2]
14 46:Ai3 polarity change[REV-Ai3]
15 47:Ai4 polarity change[REV-Ai4]
86
