Appendix
736
Appendix
16
îš„ Space Requirement (when connected to the main unit)
Width 1,694 x Depth 721 mm (Main unit + Finisher B1, when the extension tray and the
bypass tray are fully extended)
Width 1,694 x Depth 721 mm (Main unit + Finisher B1 + Booklet Maker Unit, when the
extension tray and the bypass tray are fully extended)
C3 Finisher (optional)
îš„ Type
z
Output tray x 1 : Sorting/Stacking
z
Finisher tray x 1 : Sorting (Offset available), Stacking (Offset available)
îš„ Paper Size
z
Output tray
Maximum : 12 x 19" (305 x 483 mm)
Minimum : Postcard (100 x 148 mm)
z
Finisher tray
Maximum : 12 x 19" (305 x 483 mm)
Minimum : B5
îš„ Paper Weight
z
Output tray : 52 - 300 gsm
*
z
Finisher tray : 52 -300 gsm
*
* : 52 - 55 gsm output paper may not be aligned properly depending on the paper type.
îš„ Stacker Capacity
z
Output tray 500 : sheets (A4)
z
Finisher tray
- Unstapled sheets
A4 : 3,000 sheets
B4 or larger : 1,500 sheets
Mixed size* : 300 sheets
- Stapled sheets
A4 : 200 sets or 3,000 sheets
B4 or larger : 100 sets or 1,500 sheets
Mixed size* : 70 sets or 200 sheets
* : With paper of a larger size delivered on paper of a smaller size.
z
When using 64 gsm paper
îš„ Staple
z
Capability : 50 sheets (90 gsm or less)
z
When the C3 Finisher Staple Unit 65 Sheets (optional) is installed, at the maximum of 65 sheets can be
stapled. Depending on the paper type, copies may not be aligned or stapled properly.
z
When using with Folder Unit CD1, Z-fold sheets can be stapled; however, since one Z-fold sheet of A3 or 11 x
17" paper becomes the same in thickness as 10 sheets of unfold paper, the maximum number of Z-fold
sheets of A3 or 11 x 17" paper that can be stapled is reduced. When converted into unfold sheets of paper
To Next Page
