Replacing Consumables
395
To avoid toner spills or malfunction, keep the openings of the waste toner container facing up.
Do not touch the part indicated in the figure below after pulling out the waste toner container.
3
Lay the removed waste toner container with the openings facing up, on a flat place.
4
Lower the release lever of the drum cartridge to replace.
5
Slide out the drum cartridge gently while holding its bottom, and pull it out from the device.
When removing the drum cartridge, be careful not to drop it on the floor.
Be careful not to touch the toner attached to the cartridge.
To Next Page
