Fuji Xerox DocuPrint M118 w User Manual

88
Scanner
1
For the latest driver updates for the version of OS X you are using, visit us at http://www.fujixeroxprinters.com/.
2
Maximum 1200 × 1200 dpi scanning with the Windows Image Acquisition (WIA) driver in Windows
®
XP, Windows
Vista
®
, Windows
®
7, Windows
®
8 and Windows
®
8.1 (resolution up to 19200 × 19200 dpi can be chosen by using the
scanner utility)
Printer
1
HQ1200 is a Fuji Xerox image processing technology that enables vivid, sharp and smooth quality of printing.
2
The print speed may vary depending on the type of document you print.
Print/ copy speed may decrease due to factors such as paper type, paper size, and printing condition. In periods of
heavy duty printing or copying, the device may go into cool down mode. This safety feature protects the device from
overheating, but will result in a temporary reduction in print or copy speed.
3
From Ready mode and standard tray
Model DocuPrint M118 w DocuPrint M118 z
Colour Yes
TWAIN Compliant
Yes (Windows
®
XP/ Windows Vista
®
/ Windows
®
7 / Windows
®
8 /
Windows
®
8.1 / OS X v10.7.5, 10.8.x, 10.9.x
1
)
WIA (Windows Image
Acquisition) Compliant
Yes (Windows
®
XP / Windows Vista
®
/ Windows
®
7 / Windows
®
8 /
Windows
®
8.1)
ICA Compliant Yes (OS X v10.7.5, 10.8.x, 10.9.x)
Colour
Depth
Colour 24 bit colour processing (Input)
24 bit colour processing (Output)
Greyscale 8 bit colour processing (Input)
8 bit colour processing (Output)
Resolution
Up to 19,200 × 19,200 dpi (interpolated)
2
Up to 600 × 1200 dpi (optical)
2
(from Scanner Glass)
—
Up to 600 × 600 dpi (optical)
2
(from
ADF)
Scanning Width Max. 210 mm
Model DocuPrint M118 w DocuPrint M118 z
Resolution
HQ1200 (600dpi)
1
Print Speed
2
Up to 20 pages/minute (A4 size)
Up to 21 pages/minute (Letter size)
First Print Out Time
3
Less than 10 seconds at 23 °C / 230 V
