Fuji Xerox DocuPrint M215 b

43 Basic Operation
 Front View
DocuPrint M215 fw
DocuPrint M215 b
1 Output Tray Extension 2 Center Output Tray
3 USB Drive 4 Operator Panel
5 Automatic Document Feeder (ADF) 6 Document Feeder Tray
7 Document Output Tray 8 Power Switch
9 Toner Access Cover 10 Front Cover
11 Paper Width Guides 12 Length Guide
13 Slide Bar 14 Multipurpose feeder (MPF)
15 Priority Sheet Inserter (PSI) 16 Paper Cover
*
* The paper cover is used as a tray to feed paper into the PSI as well as a cover to protect the paper
loaded on the MPF.
