Fuji Xerox DocuPrint P505 d User Manual

Device
84
Device
6

Add Exceptions
Enter an address that is not to use the proxy.
To remove an address, tap the trash box icon and select [Remove Exception].
To edit an address, tap the trash box icon and select [Edit Exception].
 Wired Proxy Setup

Enable Proxy Server
For [Multiple Proxies], select this to enable the proxy server for wired connection.

Wired Proxy Setup
Select a type of settings.

Automatic
Select this to automatically set up the proxy.

Configuration Script
Select this to allow you to enter the URL of a configurations script.

Manual
Select this to enter a server address in [Server Address]. When enabling [Password
Required], enter the login name and password.

Add Exceptions
Enter an address that is not to use the proxy.
To remove an address, tap the trash box icon and select [Remove Exception].
To edit an address, tap the trash box icon and select [Edit Exception].
LDAP

When LDAP is turned on
You can set the LDAP server settings in the [LDAP Server] screen.

When LDAP is turned off
Wait until the desired server is found, and select the server.
To specify the server by manually entering the server information, select [Manual Setup].
[Test Connection] To test the connection to the server, select [Test Connection].
Initially [Not Tested] is displayed. [Success] or [Failed] is displayed
as a result of the test.
[Server Address] Sets the server address.
[SSL/TLS] To encrypt the communication between the server and the printer,
enable [SSL/TLS].
[Directory Root] Sets the directory root.
[User Name] Enter the login name for searching in LDAP server.
[Password] Enter a password for the user specified in [User Name].
[Find Other LDAP Servers] Opens the LDAP server list.
[LDAP Communication
Report]
Outputs the report that shows the contents of the LDAP
communication transmitted and received by the machine.

Fuji Xerox DocuPrint P505 d Specifications

General

Brand	Fuji Xerox
Model	DocuPrint P505 d
Category	Printer
Language	English
