Peripherals and Optional Accessories
10
SYNC TERMINAL
SYNC TERMINAL is displayed if the built-in ash is lowered and
either no ash unit, or an incompatible ash unit, is mounted on
the hot shoe.
END
ADJUST
SYNC TERMINAL
MODE
Setting
Description
A
Flash control mode
Choose from the following options:
•
M: A trigger signal is transmitted via the hot shoe X contacts
when a picture is taken. Choose a shutter speed slower than
the sync speed; even slower speeds may be required if the
unit uses long fl ashes or has a slow response time.
•
D (OFF): The trigger signal is disabled.
B
Sync
Choose whether the fl ash is timed to fi re immediately after
the shutter opens (H/1ST CURTAIN) or immediately before
it closes (I/2ND CURTAIN). 1ST CURTAIN is recommended in
most circumstances.
