System upgrades
64 A26361-K990-Z120-1-7619, Edition 6
Floppy disk drive - removing and installing
Removing the floppy disk drive
► Remove the floppy disk drive (see "Removing an accessible drive").
1
1
2
2
► Remove the screws (1) on both sides of the slide-in module.
► Pull the disk drive out of the slide-in module (2).
Installing the floppy disk drive
► Take the new floppy disk drive out of its packaging.
2
2
► Slide the floppy disk drive into the slide-in module (1).
► Fasten the floppy disk drive with the screws (2) on both sides of the slide-in module.
► Install the floppy disk drive (see "
Installing an accessible drive").
