System upgrades
A26361-K990-Z120-1-7619, Edition 6 73
Installing WLAN module
1
2
2
► Slide the WLAN module into the slot on the front of the casing in the direction of the arrow (1).
Make sure that the screw holes for the screws are aligned.
► Fasten the WLAN module with the screws (2).
