Preparing for use
8 A26361-K678-Z121-1-7619, edition 1
Setting up the PC
!
When installing your PC, give consideration to the recommendations and safety notes in
the "Safety" manual.
Set up the PC only in its correct orientation. The points to observe are illustrated on the
following pages.
We recommend that you place your device on a surface with good anti-slip qualities. In
view of the multitude of different finishes and varnishes used on furniture, it is possible
that the rubber feet will mark the surface they stand on.
Do not expose the PC to extreme environmental conditions (see "Technical data"
chapter). Protect the PC from dust, humidity and heat.
When installing the PC, provide sufficient clearance around the PC, as indicated in the
"Technical data" chapter to ensure adequate ventilation. In order to avoid overheating, do
not cover the ventilation area of the monitor or the PC.
Do not place several PCs one above the other.
Depending on the location of your device, bothersome vibrations and noises may occur.
To prevent this, a distance of at least 3 mm should be maintained from other devices on
casing sides without ventilation surfaces. In addition, we recommend placing the device
on support feet, as these buffer vibrations.
Connect the monitor, mouse and keyboard
The ports for the monitor, mouse, and keyboard are on the rear and front of the PC.
PS/2 keyboard port / purple
PS/2 mouse port / green
Monitor port / blue
USB port / black
