Preparing for use
A26361-K678-Z121-1-7619, edition 1 9
Connecting the monitor
► Follow the instructions contained in the monitor manual to prepare the monitor for operation
(e.g. connecting cables).
► Plug the data cable into the monitor port
of the PC.
2
1
2
► Depending on your device configuration level, plug the monitor power cable into either the
PC (1) or the grounded mains outlet (2).
!
The monitor power cable may only be connected to the PC monitor socket if the monitor
current consumption is smaller than 1,5 A with 230 V or 3 A with 115 V. The values for the
monitor current consumption can be found in the technical data on the monitor or in the
operating manual for the monitor.
Connecting the mouse
Depending on the equipment level selected, your PC will be supplied with a PS/2 mouse or a USB
mouse.
Connecting a PS/2 mouse
► Connect the PS/2 mouse to the PS/2 mouse port
of the PC.
Connecting USB mouse
► Connect the USB mouse to the USB port
of the PC.
i
If you do not attach a mouse at the PS/2 mouse port
, you can disable the mouse
controller in the BIOS Setup in order to free the IRQ12 for a different application.
