A26361-K678-Z121-1-7619, edition 1 53
Technical data
Electrical data
Regulations complied with:
IEC 60950-1 / EN 60950-1 / VDE 0805 / UL 60950
CSA 22.2 No.60950
Protection class:
I
Rated voltage range: (selectable)
100 V -127 V / 200 V - 240 V
Frequency:
50 Hz - 60 Hz
Max. rated current
● Casing with monitor socket
● Monitor socket (output)
100 V -127 V / 6.0 A
200 V -240 V / 3.0 A
100 V -127 V / 3.0 A
200 V -240 V / 1.5 A
Dimensions
Width/depth/height:
202 mm/376 mm/372 mm
Weight
with the basic configuration
ca. 11 kg in basic configuration
Environmental conditions
Environment class 3K2
Environment class 2K2
DIN IEC 721 part 3-3
DIN IEC 721 part 3-2
Temperature:
● Operating (3K2)
● Transport (2K2)
15 °C 35 °C
-25 °C 60 °C
Condensation in operating must be avoided.
Clearance required to ensure adequate ventilation:
● top
● left
● front
● rear
min. 200 mm
min. 200 mm
min. 200 mm
min. 200 mm
