System expansions

A26361-K678-Z121-1-7619, edition 1 51

Installing the power supply

► Tilt and turn the power supply unit (1) so that you can place the power supply in the casing.

Watch the guide rails when doing so.

► Firmly press the power supply in the direction of the arrow (2) to deactivate locking of the

power connections.

► Fasten the knurled screws (3) on the side of the power supply.

► Then fasten the knurled screws (4) on the rear of the chasing.
