01-06
Switch the airflow [Auto] at cooling mode, and the indoor fan motor will run as shown in Fig.6.
7. MOISTURE RETURN PREVENTION CONTROL (Cooling mode& Dry mode)
When the defrost operation starts, the indoor fan runs according to cool air preventtion control for 20 seconds.
And the fan is stopped if 20 seconds have passed.
When 60 seconds have passed after defrost operation is released,
the fan runs according to cool air preventtion control
8. DEFROST OPERATION
( Fig.6 : Indoor Fan Control )
Compressor
ON
OFF
Indoor fan
Setting air flow
Indoor fan
(as shown in Table 5)
S-Lo
OFF
10 30 60 180 60 180 60 10 30
(SEC)
( Table5 : Indoor fan speed )
X zone J zone
ASTG18KMCA
ASTG22KMCA
ASTG24KMCA
740rpm
820rpm
820rpm
640rpm
720rpm
720rpm
740rpm
820rpm
820rpm
Dry
Cooling
