WALL MOUNTED TYPE ASTG18-24KMCA WALL MOUNTED TYPE ASTG18-24KMCA
SPECIFICATIONS3.
Type
WALL MOUNTED
INVERTER HEAT PUMP
Model name ASTG18KMCA ASTG22KMCA ASTG24KMCA
Power source 240 V ~ 50 Hz
Available voltage range 198 V - 264 V
Star rating index 10-star standard
Cooling 3.5 3.0 2.5
Heating 3.5 3.5 3.0
Capacity
Cooling
Rated
kW 5.00 6.00 7.10
Btu/h 17,100 20,400 24,200
Min.-Max.
kW 1.00 - 6.50 1.10 - 7.50 1.10 - 8.30
Btu/h 3,500 - 22,100 3,800 - 25,500 3,800 - 28,300
Heating
Rated
kW 6.00 7.20 8.00
Btu/h 20,400 24,600 27,3 00
Min.-Max.
kW 1.05 - 8.30 1.10 - 9.70 1.10 - 10.60
Btu/h 3,600 - 28,300 3,800 - 33,000 3,800 - 36,100
Input power
Cooling
Rated
kW
1.22 1.59 2.01
Min.-Max. 0.21 - 2.20 0.21 - 2.85 0.21 - 2.90
Heating
Rated 1.42 1.77 2.12
Min.-Max. 0.20 - 3.10 0.20 - 3.40 0.20 - 3.68
Current
Cooling
Rated A
5.2 6.7 8.5
Heating 6.0 7.5 9.0
EER Cooling
kW/kW
4.10 3.77 3.53
COP Heating 4.23 4.07 3.77
Sensible capacity Cooling kW 3.22 4.16 5.26
Power factor
Cooling
%
98 99 99
Heating 98 99 99
Moisture removal l/h (pints/h) 2.6(4.6) 2.7(4.8) 2.7(4.8)
Maximum operating
current *
Cooling
A
9.5 13.0 13.0
Heating 13.5 16.0 16.0
Fan
Airow
rate
Cooling
High
I/s (m
3
/h)
258(930) 278(1000) 311(1120)
Med 217(780) 231(830) 231(830)
Low 175(630) 189(680) 189(680)
Quiet 139(500) 161(580) 161(580)
Heating
High 258(930) 278(1000) 311(1120)
Med 217(780) 231(830) 231(830)
Low 175(630) 189(680) 189(680)
Quiet 139(500) 161(580) 161(580)
Type × Q'ty Crossow fan × 1
Motor output W 61
Sound pressure level
Cooling
High
dB (A)
46 48 49
Med 40 42 42
Low 35 37 37
Quiet 29 32 32
Heating
High 46 48 49
Med 40 42 42
Low 35 37 37
Quiet 29 32 32
Heat exchanger type
Dimensions
(H × W × D)
mm
Main: 384 x 720 x 30
Sub: 84 x 720 x 13.3
126 x 720 x 13.3
Fin pitch Main: 1.2, Sub: 1.4
Rows × Stages Main: 3 x 24, Sub: 1 x 10
Pipe type Copper
Fin type Aluminium
Enclosure
Material Polystyrene
Colour
White
Approximate colour of MUNSELL N9.25 /
Dimensions
(H × W × D)
Net
mm
295 x 940 x 270
Gross 365 x 1040 x 355
Weight
Net
kg
14
Gross 17
Connection
pipe
Size
Liquid
mm
Ø 6.35 (Ø 1/4 in.)
Gas Ø12.70 (Ø1/2 in.)
Method Flareless
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless
Drain hose
Material PP + LLDPE
Size mm Ø 13.8 (I.D.), Ø 15.8 to Ø 16.7 (O.D.)
International Protection rating IPX0
NOTES :
Specications are based on the following conditions.

•
Cooling: Indoor temperature of 27 °CDB / 19 °CWB and outdoor temperature of 35 °CDB / 24 °CWB.
Heating: Indoor temperature of 20 °CDB / 15 °CWB and outdoor temperature of 7 °CDB / 6 °CWB.
Pipe length: 7.5 m, Height difference: 0 m. (Outdoor unit - Indoor unit)
The protective function may work when using it in environment out of the temperature range mentioned above.

•
*: The maximum current is the maximum value when operated within the operation range.
