7. LOUVER CONTROL
1. VERTICAL LOUVER CONTROL
2. SWING OPERATION
Each time the button is pressed, the air direction range will change as follows:
(Function Range)
1. HORIZONTAL LOUVER CONTROL
(Function Range)
01-08
The vertical airflow direction is set automatically as shown, in accordance
with the type of operation selected.
Cooling / Dry mode Horizontal flow
Heating mode Downward flow
When the swing signal is received from the remote controller, the vertical louver starts to swing.
(Table 9 -1 : Swinging Range)
Cooling/ Dry/ Heating/ Fan mode
Fan mode ( )
1
2
3
4
5
6
7
8
Types of Air flow Direction Setting:
, , , , , , , : During Cooling/ Dry/ Heating mode
The Remote Controller's display does not change.
Use the air direction adjustments within the ranges shown above.
After beginning of Auto/ Heat mode operated and automatic defrosting operation time,
the airflow will be horizontal .
However, the Airflow direction cannot be adjusted at beginning Auto operation mode.
Range
He
a
ti
n
g mod
e
Fa
n
mo
de
(
)
The SWING operation may stop temporarily when the air conditioner’s fan is not operating,
or when operating at very low speeds.
The SWING operation may stop temporarily when the air conditioner’s fan is not operating,
or when operating at very low speeds.
Fig.8 -1 : Air Direction Range
Fig.8 -2 : Air Direction Range
1
2
3
4
5
Each time the button is pressed, the air direction range will change as follows.
To select Vertical Airflow Swing Operation
When the swing signal is received from the remote controller, the horizontal louver starts to swing.
(Table 9 -2 : Swinging Range)
Cooling/ Dry/ Heating/ Fan mode
Range
To select Horizontal Airflow Swing Operation
