PARTSPARTS
INDOOR UNIT
162012.05.29
1
2 Front Panel
Front Panel Total Assy
3
Wire Cover
Wire Shield
4
5 Air Filter
6
Intake Grille Assy
Parts numberDescriptionRef
9318423037
9318200027
9318424027
9316906006
9318202007
9318201000
7
Grille Clamper
8
9
Receiver Window
Panel Cover
Air Clean Filter Assy
9318203004
9318234008
9318235005
9305642045
9316902022
13 Bracket Panel
Remote Control
9318236019
12
Room Thermistor Holder
9311948018
15
16
14
Remote Control Holder
9379219006
10 Louver Upper
Louver Lower
9318224009
11 9318225006
15
16
10
11
14
8
1
6
7
12
9
4
2
3
5
13
