Step-3. Set the Removal Tool and rotate counterclockwise.
Removal tool of one side is cutout
for through the pipe
Fasten the Removal- A tool in a
counterclockwise by hand.
Fasten the Removal tool -B in a
clockwise by hand.
(Prevent coming off the pipe.)
Step-4. Remove the Flare less joint nut assy
The joint pipe screw is clockwise and
the removal tool is counterclockwise
with a wrench.
Remove the Flare less joint nut assy
Step-5. Remove the Removal tool
Loosen the Removal tool
in a counterclockwise by a wrench.
Remove the Guard.
Loosen the Removal tool by hand.
Remove the Removal tool.
The Removal tool is reusable.
Removal tool -A Removal tool -B
