Page #246 background imageLoading...
Page #246 background image
CN201
07 JB20 / PAP
1061 L=230
5V
C201
0.1
<F>
5V
+ C202
47/
10V
R201
47
<1/4W>
I C201
GP1UM261R
5V
D201
SLR-325MC
GREEN
D203
SLR-325MC
GREEN
D202
SLR-325DC
ORANGE
5
4
6
1
2
3
7
2
1
3
VCC
OUT
GND
INDOOR UNIT
INDICATOR PCB
K05CY-0902HSE-D0
2012.07.18 7
