Fujitsu AOTG36LATT User Manual

1 Top Panel Sub Assy 9374417032
Ref. Description Parts number
2012.07.23
6 Right Panel Sub Assy 9374416219
14 Protective Net 9375381042
13 Thermo Holder 9375211011
4 Emblem Rear 9351355005
5 Pipe Cover Front 9378861015
3 Sevice Panel Sub Assy 9374415076
2 Front Panel Sub Assy 9374414130
PARTS
OUTDOOR UNIT
3
5
6
2
1
4
14
10
9
7
8
12
11
10
Ref. Description Parts number
9
11
12
8
7
Propeller Fan Assy
Motor, DC Brushless
Condenser A Sub Assy
Condenser B Sub Assy
Reactor Assy
Base Assy
9366378020
9602843046
9374420261
9374422081
9900641016
9374166220
13
25
