Fujitsu AOYG14KBTA2 User Manual


Compact cassette type
Model: AUXG07KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.80 1.22 2.04 1.39 2.15 1.60 2.30 1.79 2.46 1.96 2.53 2.25
0.0 1.80 1.22 2.04 1.39 2.15 1.60 2.30 1.79 2.46 1.96 2.53 2.25
5.0 1.80 1.22 2.04 1.39 2.15 1.60 2.30 1.79 2.46 1.96 2.53 2.25
10.0 1.80 1.22 2.04 1.39 2.15 1.60 2.30 1.79 2.46 1.96 2.53 2.25
15.0 1.80 1.22 2.04 1.39 2.15 1.60 2.30 1.79 2.46 1.96 2.53 2.25
20.0 1.80 1.22 2.04 1.39 2.15 1.60 2.30 1.79 2.46 1.96 2.53 2.25
25.0 1.80 1.22 2.04 1.39 2.15 1.60 2.30 1.79 2.46 1.96 2.53 2.25
30.0 1.80 1.22 2.04 1.39 2.15 1.60 2.30 1.79 2.46 1.96 2.53 2.25
35.0 1.80 1.22 2.04 1.39 2.15 1.60 2.30 1.79 2.46 1.96 2.53 2.25
40.0 1.57 0.92 1.77 1.05 1.87 1.20 2.00 1.35 2.13 1.48 2.20 1.69
46.0 1.36 0.69 1.54 0.79 1.62 0.91 1.74 1.02 1.86 1.12 1.91 1.28
Model: AUXG09KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
0.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
5.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
10.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
15.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
20.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
25.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
30.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
35.0 2.03 1.35 2.29 1.54 2.42 1.78 2.59 1.99 2.77 2.18 2.85 2.50
40.0 1.76 1.02 1.99 1.16 2.10 1.34 2.25 1.50 2.40 1.64 2.48 1.88
46.0 1.53 0.77 1.73 0.88 1.83 1.01 1.96 1.14 2.09 1.24 2.16 1.43
Model: AUXG12KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.28 1.50 2.58 1.71 2.72 1.97 2.91 2.21 3.11 2.42 3.21 2.77
0.0 2.28 1.50 2.58 1.71 2.72 1.97 2.91 2.21 3.11 2.42 3.21 2.77
5.0 2.28 1.50 2.58 1.71 2.72 1.97 2.91 2.21 3.11 2.42 3.21 2.77
10.0 2.28 1.50 2.58 1.71 2.72 1.97 2.91 2.21 3.11 2.42 3.21 2.77
15.0 2.28 1.50 2.58 1.71 2.72 1.97 2.91 2.21 3.11 2.42 3.21 2.77
20.0 2.28 1.50 2.58 1.71 2.72 1.97 2.91 2.21 3.11 2.42 3.21 2.77
25.0 2.28 1.50 2.58 1.71 2.72 1.97 2.91 2.21 3.11 2.42 3.21 2.77
30.0 2.28 1.50 2.58 1.71 2.72 1.97 2.91 2.21 3.11 2.42 3.21 2.77
35.0 2.28 1.50 2.58 1.71 2.72 1.97 2.91 2.21 3.11 2.42 3.21 2.77
40.0 1.98 1.13 2.24 1.29 2.36 1.48 2.53 1.67 2.70 1.82 2.78 2.09
46.0 1.72 0.86 1.95 0.97 2.05 1.12 2.20 1.26 2.35 1.38 2.42 1.58
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 302 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOYG14-18KBTA2 OUTDOOR UNIT AOYG14-18KBTA2

Fujitsu AOYG14KBTA2 Specifications
