Fujitsu AOYG14KBTA2 User Manual


Mini duct type
Model: ARXG07KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
0.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
5.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
10.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
15.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
20.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
25.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
30.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
35.0 1.80 1.25 2.04 1.42 2.15 1.64 2.30 1.84 2.46 2.01 2.53 2.31
40.0 1.57 0.94 1.77 1.07 1.87 1.23 2.00 1.39 2.13 1.52 2.20 1.74
46.0 1.36 0.71 1.54 0.81 1.62 0.93 1.74 1.05 1.86 1.15 1.91 1.31
Model: ARXG09KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.03 1.30 2.29 1.48 2.42 1.71 2.59 1.92 2.77 2.10 2.85 2.40
0.0 2.03 1.30 2.29 1.48 2.42 1.71 2.59 1.92 2.77 2.10 2.85 2.40
5.0 2.03 1.30 2.29 1.48 2.42 1.71 2.59 1.92 2.77 2.10 2.85 2.40
10.0 2.03 1.30 2.29 1.48 2.42 1.71 2.59 1.92 2.77 2.10 2.85 2.40
15.0 2.03 1.30 2.29 1.48 2.42 1.71 2.59 1.92 2.77 2.10 2.85 2.40
20.0 2.03 1.30 2.29 1.48 2.42 1.71 2.59 1.92 2.77 2.10 2.85 2.40
25.0 2.03 1.30 2.29 1.48 2.42 1.71 2.59 1.92 2.77 2.10 2.85 2.40
30.0 2.03 1.30 2.29 1.48 2.42 1.71 2.59 1.92 2.77 2.10 2.85 2.40
35.0 2.03 1.30 2.29 1.48 2.42 1.71 2.59 1.92 2.77 2.10 2.85 2.40
40.0 1.76 0.98 1.99 1.12 2.10 1.29 2.25 1.44 2.40 1.58 2.48 1.81
46.0 1.53 0.74 1.73 0.84 1.83 0.97 1.96 1.09 2.09 1.20 2.16 1.37
Model: ARXG12KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.28 1.46 2.58 1.66 2.72 1.92 2.91 2.15 3.11 2.36 3.21 2.70
0.0 2.28 1.46 2.58 1.66 2.72 1.92 2.91 2.15 3.11 2.36 3.21 2.70
5.0 2.28 1.46 2.58 1.66 2.72 1.92 2.91 2.15 3.11 2.36 3.21 2.70
10.0 2.28 1.46 2.58 1.66 2.72 1.92 2.91 2.15 3.11 2.36 3.21 2.70
15.0 2.28 1.46 2.58 1.66 2.72 1.92 2.91 2.15 3.11 2.36 3.21 2.70
20.0 2.28 1.46 2.58 1.66 2.72 1.92 2.91 2.15 3.11 2.36 3.21 2.70
25.0 2.28 1.46 2.58 1.66 2.72 1.92 2.91 2.15 3.11 2.36 3.21 2.70
30.0 2.28 1.46 2.58 1.66 2.72 1.92 2.91 2.15 3.11 2.36 3.21 2.70
35.0 2.28 1.46 2.58 1.66 2.72 1.92 2.91 2.15 3.11 2.36 3.21 2.70
40.0 1.98 1.10 2.24 1.25 2.36 1.44 2.53 1.62 2.70 1.78 2.78 2.03
46.0 1.72 0.83 1.95 0.95 2.05 1.09 2.20 1.23 2.35 1.34 2.42 1.54
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m [Outdoor unit—Indoor unit]
