System expansions
Removing a module holder w ith reader
• Requirement: The casing is open (see "Opening the casing", Page 34).
► D isconnect the ca bles conne cted to the modu le holder.
1
1
2
► Remove the screws (1).
► Slide the module holder out of the casing in the direction of the arrow (2).
► Remove the read er from the module holder (see "
Removing the reader from
the module holder" , Page 42) and reinstall the module holder (corresponds to
"
Install ing a module holder with reader", Page 4 1).
or
► Remove the rea
der from the module holder (see "
Removing the reader fro m the module
holder", Pag
e 42) and install the metal and plastic cover in the drive bay.
► C lose the casing (see "
Closing the casing", Page 35).
Removing the reader from the module holder
1
1
► Undo the screws (1).
► Pull the reader out of the module holder
in the direction of the arrow.
