10
1. Make sure that your computer has a SCSI host
adapter already installed.
2. Make sure that your computer is turned off before
installing the MO Drive.
3. The MO Drive can be installed in many PC
configurations. Ensure that the SCSI ID setting
(Refer to Page 11) and the DIP switch (Refer to
Page 12) setting at the back of the MO Drive are
set correctly for your PC configuration.
4. Connect the MO Drive to your
computer with the SCSI cable.
5. Connect the included AC
adapter.
• The type of SCSI cable and connectors for your computer varies depending on the SCSI host adapter.
• The type of AC adapter varies depending on the country.
Connecting MO Drive
Power switch DIP switches SCSI Connectors
SCSI ID Selector
DC IN (power supply)
Power switch
SCSI cable
AC adapter
