Getting s tarted
Ports on the device
Inter facesExternaldevicesDevice
The ports available on your device depend on the selected device configuration level.
The ports are located on the front and back of th e d evice. The ports available on your
device depend on the configuration level you have selected. The standard p orts are
marked with the symbols shown below (or similar). Detailed information on the location
of the ports is provided in the manual for the mainboard.
DVI monitor port, white
Monitorport
VGA monitor port, blue
Monitorport
Microphone jack
Microphone port
Audio input (Line In)
AudioinputLinein
Headphones port
Headphones
Audio ou tput (Line O ut)
AudiooutputLineout
USB 2.0 - Universal Serial
Bus, black
USB 3.0 - Universal Serial
Bus, blue
UniversalSerialBus
LAN port
LANport
PS/2 mouse port, green
MouseportPS/2mous eport
Keyboard port, purple
Keyboardpor t
e-Sata
e-SATA port
S/PDIF
S/PDIF port
Serial port, turquoise
Serialport
DP DisplayPort
Some of the peripherals require special software (e.g. drivers) (refer to the
documentation for the peripheral and opera ting system).
14 Fujitsu
