4-18
4.6 Replacing the Front-side Lamp
5. Install a new Lamp in the reverse order of the removal. Make sure that the
clear portion of the Lamp faces down.
ATTENTION
If the Lamp is installed with the clear portion facing incorrect direction, an
error due to insufficient light occurs.
