Fujitsu fi-4860C2

7-51
7.3 Setup Mode Details
7
OPERATOR PANEL MENUS
22. Setting Interface
1) Press (Next button) or (Previous button) and let LCD display
<Screen22>.
<Screen22>
2) At <Screen22>, press (Left arrow button) or (Right arrow button), and
select the type of interface.
Available interface settings are as follows:
By pressing (Left arrow button), selection moves from (3) to (1).
By pressing (Right arrow button), selection moves from (1) to (3).
3) Press (Enter button) to confirm the setting.
Press (Exit button) at the end and the LCD display goes back to [Ready]
screen.
HINT
The blinking item is the one selected.
(1) [Auto] is blinking: If an interface board, either from third party or
optional, is installed in TPS, this interface is used. If
not, SCSI interface is used.
(2) [SCSI] is blinking: SCSI interface is used. The interface on TPS is disre-
garded.
(3) [TPS] is blinking: TPS interface is used. The SCSI interface is disre-
garded.
