7-52
7.3 Setup Mode Details
23. Setting Baud rate of TPS interface
1) Press (Next button) or (Previous button) and let LCD display
<Screen23>.
<Screen23>
2) At <Screen23>, press (Left arrow button) or (right arrow button) and
select Baud rate.
Baud rates available are as follows:
(1) 19200 bps
(2) 9600 bps
(3) 4800 bps
(4) 2400 bps
By pressing (Left arrow button), selection moves from (4) to (1).
By pressing (Right arrow button), selection moves from (1) to (4).
3) Press (Enter button) to confirm the setting.
Press (Exit button) at the end and the LCD display goes back to [Ready]
screen.
HINT
The blinking item is the one selected.
HINT
Baud rate at 9600 bps is recommended.
2
3
a
t
B
!ud
=2
00
99
6
0/0480
R
ae
/
1
0
