Fujitsu fi-5220C Getting Started Guide

fi-5120C/fi-5220C Image Scanner Getting Started 8
5. Click [INSTALL PRODUCTS], and then click
[ISIS Driver].
6. Error Recovery Guide Installation dialog box
appears.
Error Recovery Guide is an application with
which you can view on-screen information for
troubleshooting errors that may occur in the
scanner. This guide helps solve problems, so
select [Yes] to install it. You may also choose
to install it later.
7. Select a language for the installation on the
[Choose Setup Language] dialog box, and then
click the [Next] button.
8. Install the driver, following the on-screen
instructions.
9. When you see the [InstallShield Wizard Com-
plete] dialog box, click the [Finish] button.
Your computer will restart and detect the scanner. Do
not remove the Setup CD-ROM from the CD drive until
your personal computer completely starts up again.
Now the installation of the scanner driver is completed.
■ Installing QuickScan Pro™
QuickScan Pro
TM
is image capturing software based on
the ISIS standard. By using this software together with
FUJITSU ISIS, you can scan documents with the scan-
ner. Follow the procedure below to install the trial ver-
sion of QuickScan Pro
TM
that comes with this scanner.
1. Insert the Setup CD-ROM into the CD drive.
⇒ <SETUP DISK STARTUP SCREEN>
appears.
2. Click [INSTALL PRODUCTS], and then click
[QuickScan Pro (Trial)].
3. In the [Welcome to the InstallShield Wizard for
QuickScan 4.5] dialog box, click the [Next] but-
ton.
ATTENTION
After you select [Yes] for installing Error
Recovery Guide, the [Choose Setup Lan-
guage] dialog box appears. Select a lan-
guage and follow the on-screen
instructions. The Error Recovery Guide
dialog box is automatically displayed when
the installation is complete. Wait until the
installation of the ISIS starts.
ATTENTION
Depending on the operating system you are
using, you may need to do the following.
Windows 2000:
If you see the [Digital Signature not Found]
dialog box, click [Yes].
Windows Vista:
If you see the [Found New Hardware] dialog
box, select [Locate and install driver soft-
ware], and then in the [User Account Control]
dialog box, click the [Continue] button, if it is
displayed.
ATTENTION
Be sure to log on as a user with "Adminis-
trator" privileges.

Fujitsu fi-5220C Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	24 bit
Maximum scan size	210 x 297 mm
Optical scanning resolution	600 x 600 DPI
Flatbed scan speed (b/w, A4)	2 sec/page
Scanner type	Flatbed & ADF scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	SCSI, USB 2.0
Bundled software	-FJ TWAIN driver. -Scandall. -Adobe Acrobat. -ISIS Driver. -QuickScan (demo). -Soft IPC (demo). -VRS 4.1 Basic.
Dimensions (WxDxH)	302 x 569 x 229 mm
Power requirements	100-240 VAC
Power consumption (standby)	6 W
Power consumption (typical)	34 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Weight	8400 g
