Fujitsu fi-5900C

190
8.4 Multifeed Detection
5. Speficy the detection area.
Selected range: Add check mark to this checkbox first. The following setting becomes
available.
Enable/Disable: Select [Enable], if the area from [Start] to [End] is a Multifeed detection area.
Select [Disable], if the area from [Start] to [End] is not a Multifeed detection area,
but other area is a Multifeed detection area.
Start: You can specify the starting position of the selected range by the length from the
edge of the paper document.
Range: 0 to 510mm, in increments of 2mm, Start position<End position
End: You can specify the ending position of the selected range by the length from the
edge of the paper document.
Range: 0 to 510mm, in increments of 2mm, Start position<End position
35
35
35
60
60
Feeding direction
Left
Middle
Right
Document
Unit: mm
Detection areas
