Fujitsu FI-6000NS Getting Started Guide

6
3.3 Setting the Scanner Name
A scanner name may be set to provide a network alias
for the device.
1. Select the [System Settings] tab on the top
menu.
2. Select the [Scanner Name] tab on the left side
menu.
⇒ The "Scanner Name" screen appears.
3. Enter a scanner name.
Scanner names may be up to 15 characters long.
Use only alphanumeric characters (case sensitive)
and hyphens.
Scanner names cannot consist of numbers only.
4. Press the [OK] button.
⇒ The restart confirmation screen appears.
5. Press the [Later] button.
⇒ The current scanner name, or changed scanner
name after next restart, is displayed.
Restart may be performed after all necessary settings
have been completed.
Continue with the Region/Timezone settings.
3.4 Setting the Region/Timezone
1. Select the [System Settings] tab on the top
menu.
2. Select the [Region/Timezone] tab on the left
side menu.
⇒ The "Region/Timezone" screen appears.
3. Press the [List] button for the "Timezone" input
field.
The default timezone is "(GMT+09:00) Osaka,
Sapporo, Tokyo".
⇒ A list of timezones appears.
4. Select a timezone.
ATTENTION
Do not use a name that is already
being used in the network.
Name duplication will cause a network
connection error.
HINT
If the scanner name is the same as one
already in use, network communication
problems will occur. In this case, try the
following steps:
1. Disconnect the LAN cable and turn the
scanner off.
2. Reboot the scanner with the LAN cable
still disconnected, and enter a non-
duplicate scanner name.
3. Reboot the scanner again.
4. Re-connect the LAN cable to the scanner.

Fujitsu FI-6000NS Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	24 bit
Maximum scan size	210 x 297 mm
Optical scanning resolution	600 x 600 DPI
Display	TFT
Scanner type	Flatbed & ADF scanner
Product color	Gray
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, Image
Sensor type	CCD
Scan file formats	JPG, PDF, TIFF
Scanning noise level	59 dB
Daily duty cycle (max)	- pages
Auto document feeder (ADF) input capacity	50 sheets
Minimum scan area (ADF)	53 x 74 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A7, A8
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 127 g/m²
Standard interfaces	Ethernet, SCSI-3
Server operating systems supported	Windows 2000 Server, Windows Server 2003
Input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	10 W
Power consumption (typical)	88 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS
Cabling technology	10/100BASE-T(X)
Dimensions (WxDxH)	315 x 415 x 281 mm
Networking features	Fast Ethernet
Supported network protocols	TCP/IP, DHCP, SMTP, SMB, LDAP, NTP

Weight and Dimensions

Depth	415 mm
Width	315 mm
Height	281 mm
Weight	13000 g
