Fujitsu FI-6000NS Getting Started Guide

10
Chapter 4 Downloading the Manual
In addition to this "Getting Started" guide, a "Network
Scanner fi-6000NS Operator's Guide" is also available.
The "Network Scanner fi-6000NS Operator's Guide"
contains information about scanner settings, scanner
administration, and scanner operations.
Consult this manual when using the scanner.
Login as the administrator via the web interface to
download the "Network Scanner fi-6000NS Operator's
Guide".
The download procedure is as follows:
To download the manual from the scanner, the
following requirements apply:
* Adobe® Reader® can be downloaded from the
following site.
http://www.adobe.com/
1. Specify the scanner name as a URL in the web
browser's location bar.
For example, when the scanner name is
"SCAN001":
use "http://SCAN001/"
For URL's, an IP address can be set instead of a
scanner name. If the IP address is
xxx.xxx.xxx.xxx, the specified URL is
http://xxx.xxx.xxx.xxx/.
⇒ The "Login" screen appears on the web
browser.
2. Press the [Download Manual] button.
⇒ The "File Download" screen appears.
3. Press the [Save] button.
⇒ The "Save As" window appears.
4. Select a folder and enter a file name.
5. Press the [Save] button.
⇒ The file is saved.
The "Network Scanner fi-6000NS Operator's Guide" is
a PDF file, and can be viewed with Adobe® Reader®.
Next, perform a scan test.
Software English versions:
• Microsoft® Internet Explorer 6 SP2
or later
• Adobe® Reader® (*)
• Any Windows® operating system
which supports the above software
Hardware • Any client PC which runs the
supported software
• XGA monitor or better
• LAN cable

Fujitsu FI-6000NS Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	24 bit
Maximum scan size	210 x 297 mm
Optical scanning resolution	600 x 600 DPI
Display	TFT
Scanner type	Flatbed & ADF scanner
Product color	Gray
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, Image
Sensor type	CCD
Scan file formats	JPG, PDF, TIFF
Scanning noise level	59 dB
Daily duty cycle (max)	- pages
Auto document feeder (ADF) input capacity	50 sheets
Minimum scan area (ADF)	53 x 74 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A7, A8
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 127 g/m²
Standard interfaces	Ethernet, SCSI-3
Server operating systems supported	Windows 2000 Server, Windows Server 2003
Input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	10 W
Power consumption (typical)	88 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS
Cabling technology	10/100BASE-T(X)
Dimensions (WxDxH)	315 x 415 x 281 mm
Networking features	Fast Ethernet
Supported network protocols	TCP/IP, DHCP, SMTP, SMB, LDAP, NTP

Weight and Dimensions

Depth	415 mm
Width	315 mm
Height	281 mm
Weight	13000 g
