Fujitsu FI-6000NS Getting Started Guide

Network Scanner fi-6000NS Getting Started 7
5. Select whether "Daylight Savings Time" should
be on or off.
This option is not shown for timezones where
daylight savings time is not used.
6. Press the [OK] button.
⇒ The Region/Timezone is set.
Continue with IP address/DHCP settings.
3.5 Setting the IP Address/DHCP
An IP address must be set in order to connect the
scanner to a network.
1. Select the [Network Settings] tab on the top
menu.
2. Select the [IP Address] tab on the left side
menu.
⇒ The IP address/DHCP screen appears.
3. Set the scanner's IP address. This may be
done automatically, by pressing the DHCP [On]
button.
The IP address may also be set manually, by
pressing the DHCP [Off] button and entering
the following numerical addresses:
• IP Address
• Subnet Mask
• Default gateway
4. Press the [OK] button.
⇒ The information entered is set.
Continue with the DNS settings.
ATTENTION
Do not use an IP address that already
exists in the network.
IP address duplication will cause an
error during setup.
HINT
If the IP address is the same as one
already in use, network communication
problems will occur. In this case, try the
following steps:
1. Disconnect the LAN cable and turn the
scanner off.
2. Reboot the scanner with the LAN cable
still disconnected, and enter a non-
duplicate IP address.
3. Re-connect the LAN cable to the scanner.
When DHCP is set to "On", the following
settings are assigned by the DHCP:
• IP Address
• Subnet Mask
• Default Gateway
• DNS Server
• WINS Server
Even if DNS or WINS server is set, priority
is given to the scanner settings over the
DHCP settings.

Fujitsu FI-6000NS Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	24 bit
Maximum scan size	210 x 297 mm
Optical scanning resolution	600 x 600 DPI
Display	TFT
Scanner type	Flatbed & ADF scanner
Product color	Gray
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, Image
Sensor type	CCD
Scan file formats	JPG, PDF, TIFF
Scanning noise level	59 dB
Daily duty cycle (max)	- pages
Auto document feeder (ADF) input capacity	50 sheets
Minimum scan area (ADF)	53 x 74 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A7, A8
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 127 g/m²
Standard interfaces	Ethernet, SCSI-3
Server operating systems supported	Windows 2000 Server, Windows Server 2003
Input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	10 W
Power consumption (typical)	88 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS
Cabling technology	10/100BASE-T(X)
Dimensions (WxDxH)	315 x 415 x 281 mm
Networking features	Fast Ethernet
Supported network protocols	TCP/IP, DHCP, SMTP, SMB, LDAP, NTP

Weight and Dimensions

Depth	415 mm
Width	315 mm
Height	281 mm
Weight	13000 g
