C156-E097-01EN 5 - 11
Clean the cartridge at clean place. Put a disposable groves at
cleaning so that the figureprint does not put on the disk media
(recommendation).
1) Slide the shutter completely open.
Figure 5.6 Cleaning procedure (1)
2) Set the cartridge with keeping label side down and shutter open to the shutter stopper of
the setting case as shown in Figure 5.7.
Figure 5.7 Cleaning procedure (2)
Shutter stopped
Setting case
Setting case as shown
Disk media
Spindle
Shutter
Cartridge
